Custom PA66+GF30 Precision Injection Molded Structural Frame

This high-precision structural frame is a hallmark of our advanced injection molding capabilities. Engineered for maximum rigidity and dimensional stability, this component features an intricate web of internal ribbing (cross-reinforcement) designed to prevent warping and withstand high mechanical stress.

Commonly used as a foundational chassis for automotive dashboard modules or industrial control systems, this part is molded using Glass Fiber Reinforced Polyamide (PA66+GF30). Our state-of-the-art facility utilizes high-tonnage precision injection machines to ensure that even with such complex geometry, every mounting point and snap-fit maintains perfect alignment for seamless downstream assembly.

Inquire Now ADD TO CART

PRODUCT DETAILS
PRODUCT REVIEWS
ONLINE MESSAGE
RELATED PRODUCTS

PRODUCT DETAILS

Technical Specifications (Quick Data Reference)

Parameter	Value / Specification
Manufacturing Process	Precision High-Pressure Injection Molding
Primary Material	PA66 + 30% Glass Fiber (Customizable)
Part Dimensions	Up to 800mm (Large Format Capacity)
Dimensional Tolerance	±0.05mm – ±0.1mm
Surface Texture	Matte Finish (VDI 24/27) or Functional Erosion
Mold Steel Type	718H, S136, or H13 (Hardened Steel)
Quality Compliance	IATF 16949, ISO 9001:2015, UL Certified

Core Advantages & Features

Superior Stiffness-to-Weight Ratio: The optimized honeycomb ribbing design provides the structural strength of metal while significantly reducing the overall weight, which is critical for EV range and fuel efficiency.
Complex Geometry Integration: This single molded piece integrates dozens of mounting bosses, cable routing clips, and precision snap-fits, eliminating the need for multiple sub-assemblies and reducing labor costs.
Thermal & Chemical Resistance: Utilizing PA66+GF ensures the component remains stable in high-temperature environments (up to 120°C) and resists common automotive fluids and industrial chemicals.
Zero-Defect Production: Through rigorous Moldflow Analysis, we optimize gate locations to eliminate weld lines and air traps in these thin-walled but high-strength sections.

FAQ

Q1: How do you prevent warping in such a large, rib-heavy part? A: We use advanced Moldflow Simulation to calculate shrinkage rates and optimize cooling channel placement. Our high-precision temperature control units ensure uniform cooling across the entire tool surface.

Q2: Can you provide material certification for PA66+GF30? A: Yes. We provide full COA (Certificate of Analysis) and UL yellow cards for all engineering plastics used, ensuring compliance with your specific safety and performance standards.

Q3: What is your typical lead time for a complex structural mold like this? A: For a tool of this complexity, the lead time is generally 35-45 days, including DFM, mold design, T1 sampling, and dimensional verification.

Q4: Do you offer DFM (Design for Manufacturability) advice? A: Absolutely. Our engineering team provides a Free DFM Analysis for every project, suggesting optimizations for wall thickness, draft angles, and rib design to improve quality and reduce costs.

Packaging & Delivery

Packaging: Anti-rust plastic bags, foam lining, and sturdy master cartons to prevent damage during transit. Custom packaging available for OEM production lines.
Lead Time: Mold development: 15-25 working days; Mass production: 7-15 working days (adjustable based on order quantity).
Payment Terms: T/T, L/C, and other standard international trade terms supported.
Logistics Options: DHL, FedEx, sea freight, air freight, and other global shipping solutions available.
